CCT Parking garage canopy light

CCT selectable orange black.png
wattage selectable orange black.png

CCT Selectable       Wattage selectable

Application

The selectable LED parking garage canopy light is a versatile and energy-efficient lighting solution designed to meet the diverse needs of commercial and outdoor covered applications such as parking garages, walkways, entryways, gas stations, and building overhangs.

Featuring field-selectable wattage options of 30W, 45W, and 60W, this fixture allows installers to adjust light output to match specific mounting heights and illumination requirements, reducing energy consumption while maintaining optimal brightness.



In addition, the selectable color temperature settings of 3000K, 4000K, and 5000K provide flexibility to create warm, neutral, or daylight lighting environments, ensuring the right ambiance and visibility for any location. Engineered with high-efficiency LED technology, the canopy light delivers consistent, uniform illumination with excellent lumen performance and reduced maintenance compared to traditional HID or fluorescent fixtures.



Its durable construction is designed to withstand demanding environments, offering reliable operation and long service life. Easy to install in both new construction and retrofit projects, this canopy light combines adaptability, performance, and efficiency in one compact fixture, and it is backed by a 5-year warranty for dependable, worry-free operation.

Sensor receiver built-in into the center of the fixture to make it easy and convenient to add a motion sensor. The sensor is sold separately.

Pic 1.png
Features

* Color temperature tunable : 3K, 4K and 5K

* Philips Lumileds 2835

* Wattage selectable: 30W/45W/60W

* Lumens: 131 Lm/W @ 7860 Lumens in 3K ; 145 Lm/W @ 8700 Lumens in 4K and 140 Lu/w @8400 Lm in 5K

* Universal 100-277V AC input voltage

* Dimmable with 0-10V

* Sensor receptacle built-in

* Light fixture and finish endurance tested to withstand 3000 hours of elevated ambient salt fog conditions as defined in ASTM Standard B 117

* High efficiency LED Driver

* Power factor > 0.90

* Total harmonic distortion <20%

* Color rendering Index >80

Warranty & Listing

* UL listed

* DLC premium Listed

* IP65 rating

* 5-year warranty on all electronics and housing

* -40 F to 122 F operating temperature.

Motion sensor

* Motion sensor HD07BR optional - Sold separately

Dimensions
Exploded view.png
Ordering information
